P5/10 Outdoor with Die-casting Aluminum Cabinet Rental LED Display Screen

Product Categories
Guangzhou chengwen photoelectric technology co.,ltd.
Contact Now

P5/10 Outdoor with Die-casting Aluminum Cabinet Rental LED Display Screen

Brand Name : Cheng Wen

Model Number : CW-P5/10

Certification : CE

Place of Origin : Made in China

MOQ : 1sqm

Price : $3418-708/sqm

Payment Terms : T/T, Western Union, MoneyGram

Supply Ability : 3000 pcs/month

Delivery Time : 3-10/days

Packaging Details : Flight case

Model Size : 320mm*160mm

Pixel Pitch : 5mm/10mm

Pixel Configuration : 1R1G1B

Brightness of White Balance : 6500-7500cd/m²

Contact Now

Specification



Item Parameter
Model Number P5 -8S
Module size 320mm*160mm
Pixel pitch 5mm
Pixels Density 40000 dots/m2
Pixel configuration 1R1G1B
Package mode SMD2727
Pixel resolution 64dots(W)*32 dots(H)
Drive type Constant drive
Scan mode 1/8scan
Port type HUB75
Brightness of white balance 6500-7500cd/m2
Dimension 960mm*960mm
Quantity of Module 18
Power supply 5V/40A
Pixel per cabinet 192*192
Weight 28kg
Best viewing distance >10m
Best viewing distance 160°(W) 120°(H)
Temperature

storage:-35℃～+85℃

working:-20℃～+50℃
Operation humidity 10%-95%
Thickness 15mm
Protection classification IP65
Working voltage AC220V±10%
Max Power consumption 800W/S
Average Power consumption 450W/S



Product name P10-4S
Pixel Pitch(mm)W*H 10MM
Driving Mode constant current
Pixel Density(dot/m²) 10000
LED type SMD3528
Cabinet Size(mm)W*H 960*960MM
Cabinet Resolution 32DOTS(W)*16DOTS(W)
Viewing Distance(m) above 10m
Brightness(full white)(cd/m²) 6500-6800cd/m²
Refresh Rate 1920HZ
Transparency Rate >80%
Weight(kg/pc) 27.6 kg/pc
Viewing Angle H:160°V:160°
Max. Power Consumption (W/m²) 800
Avg. Power Consumption (W/m²) 240
Signal Input HDMI,DVI,VGA,RF,S-Video,RGB,RGBH,YUV,YC&Conposition,etc
Working Voltage 380V±10% AC50HZ
Working Environment -10℃～+45℃ 10%～80%RH
Life Span Time ≥100000hours
Package Flight Case/Wooden Case
Application shopping mall ,supermarket,car shop



Trade Terms:



Price term EXW , FOB (EXW Price in Guang zhou)
Payment T/T, Western ,paypal
Shipping method By express(DHL ,UPS,TNT,FedEx ), ship by sea or air
Sample Order/Time Accept / 2 days
Production time 3-7 days after receiving payment ,depend on the quantity
Packing

1.Carton Packing(PE bag and EPE for safeguard that can protect from damage)

2. Flight case
Warranty 2 years
After sells service In time, High efficiency, Satisfiable







P5/10 Outdoor with Die-casting Aluminum Cabinet Rental LED Display Screen





P5/10 Outdoor with Die-casting Aluminum Cabinet Rental LED Display Screen
